Elevate your emergency backup power solutions with the AIMS Power 6000 Watt Low-Frequency Inverter Charger, now available for purchase on Appliance Guys! With an impressive 6000 watts of continuous power and a 18,000-watt surge for up to 20 seconds, this inverter ensures you're always prepared for power outages. The direct-connect terminal block allows users to surpass the 6000-watt capacity and harness its 300% surge power. AIMS Power stands out with top-of-the-line technology, offering a repairable unit with a free one-year warranty and lifetime phone support.

Appliance Guys Exclusive Benefits:

• Lifetime Phone Support: Expert assistance always within reach.
• Open 7 Days a Week: Convenience tailored to your schedule.
• Price Match Guarantee: Shop confidently, knowing you're getting the best deals.

Features

Features

• Reliable Emergency Backup: 6000 watts continuous power, 18,000 watts surge for 20 seconds.
• Direct-Connect Terminal Block: Surpass capacity, harness 300% surge power.
• Solar Panel Compatibility: Recommend recharging with AIMS Power solar panels for cleaner power.
• Global Operability: Output 120 Vac, switchable between 50Hz and 60Hz, suitable for international use.
• Sustainable Efficiency: 48-volt DC input for minimal power loss, ideal for large systems.
• Versatile Applications: Perfect for renewable solar, off-grid, and emergency backup power.
• Rugged Construction: Marine-coated, over-temperature protection, and dual thermally-controlled fans.
• Smart Charging: 80 Amp multi-stage charger compatible with gel, lead, AGM, and Lithium batteries.
• Flexible Settings: 60Hz or 50Hz selectable via dip switch, 7 battery type settings for charger.
• Optional Power Save Mode: Efficient power usage with the optional 25W power save mode.

Specifications

Specifications

• Continuous Output Power: 6000 Watts.
• Surge Rating: 18,000 Watts (20 Seconds).
• Output Waveform: Pure Sine/Same as input (Bypass Mode).
• Output Voltage: 100-110-120Vac.
• Nominal Efficiency: >88% (Peak).
• Line Mode Efficiency: >95%.
• Output Frequency: 50Hz /- 0.3Hz / 60Hz /- 0.3Hz.
• Transfer Time: 10ms (Max).
• THD: < 10% DC.
• Ambient Operating Temperature: 14°F to 122°F (-10°C to 50°C).

Input Specifications:

• Nominal Input Voltage: 48.0Vdc.
• Low Battery Alarm/Trip: 42.0Vdc-44.0Vdc/40.0Vdc-42.0Vdc.
• High Voltage Alarm: 64.0Vdc.
• Low Battery Voltage Restart: 53.2Vdc.
• Idle Consumption: 4.16 amps DC.
• Power Saver Mode Idle Consumption: <0.83 amps DC.

Charger Specifications:

• Output Voltage: Depends on Battery Type.
• Charger Rate: 60A.

Dimensions & Weight

Dimensions & Weight

• Unit Weight: 79 lbs.
• Unit Size (L x W x H): 27.88 x 8.5 x 7.0 inches.
• Shipping Weight: 84 lbs.
• Shipping Size (L x W x H): 30.5 x 14.5 x 13.75 inches.
